X Series Diesel 5.0-7.0T

Maxlion's X Series Forklift is designed for the driver. Maxlion engineers have focused on improving the comfort and safety for new series forklifts, with lower noise levels, less vibration, more safety, and every small detail carefully designed prepared for the driver.

Simple, Solid, Durable

Ergonomic Design for Comfort

High Cost-effectiveness

Easily Maintenance

Consult Now Maxlion

Concept Description

Video

On-site show

Equipment Application

"Maxlion independently developed the new product, an innovative line of intenal combustion counterbalance forklifts, integrating cutting-edge technologies from its original products. This revamped series prioritizes enhanced aesthetics, energy efficiency, eco-friendliness, operator comfort.security, and reliability. These advancements aim to position the new series as a top-tier forklift range meeting diverse operational needs on a global scale"

Features

Simple, Solid, Durable Ergonomic Design for Comfort Premium Exterior Design

Application

Retail & Wholesale

Warehousing & Logistics

Manufacturing

Food Beverage

Forestry wood & Agriculture

Construction & Mining

Ports & Terminals

Forklift Container Unloading

Tech Specs

Characteristics

Model			FD50T	FD70T
Power type			Diesel
Optional engine			Cummins QSF3.8、Mitsubishi S6S-T
Rated capacity			5000kg	7000kg
Load centre			600mm	600mm
Min. turning radius			3230mm	3370mm
Lift height			3000mm	3000mm
Overall Dimension	Length(without fork)		3500mm	3640mm
Width			1995mm	1995mm
Height when mast lowered			2500mm	2500mm
Height to safeguard			2495mm	2495mm
Speed	Travel(Unladen/Laden)	km/h	24/22	24/22
Lifting(Unladen/Laden)		mm/sec	520/380	500/380
